SERVICE MODE · ADJUSTMENT
13
4-6-3 FR MI-COM Input Port
4-6-4 FR MI-COM A/D Port
PIN NAME Description CS Function ADDR
AA16
ZOOMKEY Zoom key output 0 02 0002
TELE
side
WIDE
side
AC17
TEMP Lens thermometer output 0 02 0003
X15
Y GYRO YAW side GYRO output 0 02 0004
AB16
P GYRO PITCH side GYRO output 0 02 0005
Y15
I ENC IRIS ENC output 0 02 0006 Small diaphragm Open
AA15
MSW AD Mechanical position 0 02 000A
AC15
DEW DEW detection 0 02 000B
Y14
CAS IN Cassette det ection 0 02 000C
Casset t e
inserted
Cassette
not inserted
AC14
WIDE DET Wide signal detection 0 02 000D
AA14
TAPE TOP Beginning detection 0 02 000E
AB14
TAPE END Ending detection 0 02 000F
AD DATA (00
〜
FF)
Intermediate
PIN NAME Description CS Function ADDR DATA BIT
P6
SDE T
S JA CK det ec t io n
0010000 5
W1
USB DET USB Detect 0 01 0009 5
X5
CARD DET CARD detection 0 01 0009 4
E3
REC PROOF Tape recording inhibition 0 01 000A 7
U6
CARD PRO Card recording inhibit ed 0 01 000A 2
