MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
22
5-4 Camera Section Adjustment
Notes)
(1) Each adjustment data (5-4-1 to 5-4-5) becomes effective after it is written into the DATA as mentioned in 5-4-6. If power must be
turned OFF/ON during each adjustment, be sure to perform the DATA write procedure as mentioned in 5-4-6.
(2) The adjustments from 5-4-2 through 5-4-5 must be carried out in series.
Preparation)
(1) For camera section adjustment, take the product condition.
(2) Adjustment condition (initial condition)
Tape/Card : Tape
Program AE : Auto Mode
AF : OFF
Image stabilizer : OFF
Chart : Standard angle of view
5-4-1 Iris Adjustment
CHART
SPEC. Automatic adjustment.
Procedure)
(1) Referring to the table shown below, adjust the Iris.
5-4-2 WB Adjustment (1)
CHART Light box (5600°K)
SPEC. Automatic adjustment
Procedure)
(1) Referring to the table shown below, carry out WB adjustment (1).
Note) In this adjustment, color balance gain data is set to FF. Be sure to carry out color balance adjustment de-
scribed in 5-4-3.
STEP PROCEDURE Microcomputer operation
IRIS CS Function MD ADDR DT ST
1 1) Make the setting shown at right. 2 08 ST 3000 00
2) Perform storing.
↑↑
WR
↑↑
Adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑
05 Adjustment is completed.
Completion with ST:05 (ST:09 NG)
MONITOR
STEP PROCEDURE Microcomputer operation
WB (1) CS Function MD ADDR DT ST
1 1) Make the setting shown at right. 2 08 ST 3002 00
2) Perform storing.
↑↑
WR
↑↑
Adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑
05 Adjustment is completed.
Completion with ST:05 (ST:09 NG)
MONITOR
To Next Page
