MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
34
5-8 Recorder Section Adjustment
Note)
(1) Each of the adjustment data (5-8-1 to 5-8-3) becomes valid when 5-8-5 flash memory writing is made. When turning power OFF/
ON during each adjustment, be sure to carry out 5-8-5 flash memory writing.
Preparation)
(1) Except for the tape-path adjustment, carry out adjustment in the product state.
5-8-0 LCD PCB Setting Destination
When mounting the LCD P.C.B of service part, perform the following adjustment.
5-8-1 SWP Adjustment
MODE Playback of color bar master (DY9-1381-000)
SPEC. Automatic adjustment
Procedure)
(1) While playing back the color bar master, carry out SWP automatic adjustment referring to the table shown below.
STEP PROCEDURE MONITOR Microcomputer operation
C.FG(AUTO) CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0003 --
2) Perform storing.
↑↑
WR
↑↑
Automatic adjustment is in progress.
(press the PAUSE button.)
㸡㸡
RD
㸡㸡
Automatic adjustment is completed.
5-8-2 C. FG Adjustment
MODE Playback of color bar master (DY9-1381-000)
SPEC. Automatic adjustment
Procedure)
(1) While playing back the color bar master, carry out C.FG automatic adjustment referring to the table shown below.
STEP PROCEDURE MONITOR Microcomputer operation
SWP (AUT O) CS Function MD ADDR DT
1 1) Make the setting shown at right. 0 08 ST 0001 --
2) Perform storing.
↑↑
WR
↑↑
Automatic adjustment is in progress.
(press the PAUSE button.)
㸡㸡
RD
㸡㸡
Automatic adjustment is completed.
STEP PROCEDURE MONITOR Microcomputer operation
CS Function MD ADDR DT
1 1) Make the setting shown at right. 4 10 ST 0003 --
2) Add "09" to the current value, and
store the result data.
㸡㸡
RD
㸡 ADJ
To Next Page
