MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
26
5-6 CVF Adjustment
Notes)
(1) Each adjustment data (5-6-2 to 5-6-7) becomes effective after it is written into the DATA as mentioned in 5-6-8. If power must be
turned OFF/ON during each adjustment, be sure to perform the DATA write procedure as mentioned in 5-6-8.
(2) The adjustments from 5-6-2 through 5-6-7 must be carried out in series.
Preparation)
(1) Carry out CVF adjustment in the product condition.
(2) For copying black and white master, the service manual CD-ROM and SD card are required.
After formatting the SD card, copy the data to an SD card from the appendix of the service manual CD-ROM.
Destination folder of saving : DCIM/101CANON, File name: IMG0001.jpg
(3) Adjustment condition (initial condition)
Tape/Card : Card
5-6-1 Forced CVF ON
Procedure)
(1) Referring to the table shown below, make the setting.
CS Function MD ADDR DT
Forced CVF ON 1) Make the setting shown at right
1 10 ST 0017 10 Start of setting
2) Perform storing.
↑↑
RD
↑↑
Completion of setting
(press the PAUSE button.)
STEP PROCEDURE
MONITOR
Adjustment points and range
CS Function MD ADDR DT
CVF Frequency 1) Make the setting shown at right
411ST0002
"ADJ"
Start of setting
Adjustment 2) Perform storing.
↑↑
RD
↑
ADJ Completion of setting
(press the PAUSE button.)
STEP PROCEDURE
MONITOR
Adjustment points and range
5-6-2 CVF Frequency Adjustment
M. EQ. Frequency counter
TP. Extension connector - pin 2 (EVF HD)
SPEC. 15.625 ± 0.1kHz
Preparation)
(1) Carry out adjustment according to the table shown below.
