MVX250i E, MVX200i E, MVX200 E
TECHNICAL DESCRIPTION
8
3-2 Operation at Charging
3-2-1 Conditions to Start Charging
When the following conditions are satisfied, the MODE MI-COM (IC100) controls the IC 1810 starts charging.
If the conditions (4) and (5) are not satisfied, a charge error is indicated.
Conditions Detection Source of detection
1 Main unit power is turned OFF MODE MI-COM -
DC jack is connected. MODE MI-COM pin 71 DC JACK
DC JACK DET
Power supplied from DC jack MODE MI-COM pin 80 DC IN
DC V DET
UNREG voltage is 8.4 ±0.3 V. MODE MI-COM pin 87 VTR UNREG.
BATT.AD
Battery temperature is within the range of MODE MI-COM pin 88 Battery T terminal
-6.8°C to 49.3°C. BATT.INFO
2
3
4
5
