MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
23
5-4-3 Color Balance Adjustment
CHART Lightbox (5600°K), and color bar chart
M.EQ. Vectorscope
TP/TRIG. VIDEO OUT
SPEC. R : × 2.0 (ratio to burst) 90°, Ye : × 1.0 (ratio to burst) 180°
Procedure)
(1) For manual adjustment of color balance, change data at the following four addresses while observing a vectorscope.
5-4-4 WB Adjustment (2)
CHART Light box (5600°K), and CCA12 filter
SPEC. Automatic adjustment
Procedure)
(1) Referring to the table shown below, carry out WB adjustment (2).
STEP PROCEDURE Microcomputer operation
WB (2) CS Function MD ADDR DT ST
1 1) Make the setting shown at right. 2 08 ST 3004 00
2) Perform storing.
↑↑
WR
↑↑
Adjustment is in progress.
(press the PAUSE button.)
↑↑
RD
↑
05 Adjustment is completed.
Completion with ST:05 (ST:09 NG)
MONITOR
STEP PROCEDURE Microcomputer operation
CB (MANUAL) CS Function MD ADDR DT
R GAIN 1) In the setting shown at right, adjust relevant data. 2 08 ST 3007 "ADJ" Adjustment is in progress.
2) Perform storing.
↑↑
RD
↑
ADJ Adjustment is completed.
(press the PAUSE button.)
Ye GAIN 1) Make the setting shown at right.
㸡㸡
ST 3008 "ADJ" Adjustment is in progress.
2) Perform storing.
㸡㸡
RD
㸡
ADJ Adjustment is completed.
(press the PAUSE button.)
Ye PHASE 1) Make the setting shown at right.
㸡㸡
ST 3009 "ADJ" Adjustment is in progress.
2) Perform storing.
㸡㸡
RD
㸡
ADJ Adjustment is completed.
(press the PAUSE button.)
R PHASE 1) Make the setting shown at right.
㸡㸡
ST 300A "ADJ" Adjustment is in progress.
2) Perform storing.
㸡㸡
RD
㸡
ADJ Adjustment is completed.
(press the PAUSE button.)
MONITOR
