MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
19
5-2-2 Cam Correction (AUTO)
CHART CZ adjustment chart
SPEC. Automatic adjustment
Procedure)
(1) Quit the service mode, and turn power OFF/ON.
(2) Perform the cam correction by following the table below.
(3) Quit the service mode, turn power off/on, and then check that proper focusing can be attained in normal zooming operation (AF
OFF).
(4) If the result is NG, perform 5-2-1 : CZ automatic adjustment and 5-2-2 : Cam correction (AUTO).
STEP PROCEDURE Microcomputer operation
CAM CORRECTION CS Function MD ADDR DT ST2
1 1) Make the setting shown at right. 2 08 ST 3101 00
2) Perform storing.
↑↑
RD
↑
01
(press the PAUSE button.)
2
3 1) Make the setting shown at right. 2 08 ST 3202 --
↑↑
WR
↑↑
2) Perform storing.
↑↑
RD
↑
02 Correction value measurement.
(press the PAUSE button.) Completion with ST2:02.
4 1) Make the setting shown at right. 2 08 ST 3104 --
2) Perform storing.
↑↑
RD
↑
04 Correction value calculation.
(press the PAUSE button.) Completion with ST2:04.
5 1) Make the setting shown at right. 2 08 ST 3105 --
2) Perform storing.
↑↑
RD
↑
AA Completion of correction value writing.
(press the PAUSE button.) Completion with ST2:AA.
6 1) Make the setting shown at right. 0 08 ST 0081 -- Preparation for flash memory updating.
2) Perform storing.
↑↑
RD
↑↑
Execut ion of flash memory updat ing.
(press the PAUSE button.)
Cancel the service mode, and set the zoom position to the telephoto end. After focus movement is stopped,
turn OFF the AF function.
MONITOR
