Canon MVX200 E - Cleaning Mode; Commands Particular to Camera

MVX250i E, MVX200i E, MVX200 E
SERVICE MODE · ADJUSTMENT
10
4-3 Cleaning Mode
When cleaning the head with hard-type cleaning tape (DY9-1384-000), set up the cleaning mode according to the procedure given
below.
Note : After head cleaning, be sure to restore the settings to normal.
4-4 Commands Particular to Camera
<Outline>
(1) The commands particular to camera are provided for checking the operation.
(2) Make preparation according to the table below and carry out the desired commands particular to camera.
(3) To restore any setting back to the original status, press the PAUSE key (STORE) for each item again in the “ST” mode.
Turning the power OFF/ON resets all the settings.
STEP PROCEDURE MONITOR Microcomputer operation
CS Function ADDR MODE DT
1 1) Make setting shown at right. 0 10 0111 ST --
2) Increases DT by 2.
㸡㸡 㸡㸡
--
(Change bit-02 to 1 from 0.)
(Example: 80
㸢
82)
3) Perform STORE. (Press PAUSE key.
㸡㸡 㸡
RD -- Completion of cleaning mode setup
2 1) Change over to the normal mode and turn OFF the power supply. Resetting of cleaning mode
STEP PROCEDURE Microcomputer operation
CAM SPECIAL COMMAND CS Function ADDR MODE DT
WB SET 1) Make setting shown at right. 2 08 3300 ST --
2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- WB is set.
WB 1) Make setting shown at right. 2 08 3301 ST --
LOCK 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- WB is locked.
WB 1) Make setting shown at right. 2 08 3302 ST --
TURBO 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- WB high-speed setting mode
WB 1) Make setting shown at right. 2 08 3303 ST --
OUTDOOR 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- WB outdoor mode
WB 1) Make setting shown at right. 2 08 3304 ST --
INDOOR 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- WB indoor mode
IRIS 1) Make setting shown at right. 2 08 3305 ST --
OPEN 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- T he iris is opened forcibly.
IRIS 1) Make setting shown at right. 2 08 3306 ST --
CLOSE 2) Execute ST ORE. (Press PAUSE.)
㸡㸡 㸡
RD -- T he iris is closed forcibly.
ND ON 1) Make setting shown at right. 2 08 3307 ST --
2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- ND inserted
ND OFF 1) Make setting shown at right. 2 08 3308 ST --
2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- ND in standby state
AGC 1) Make setting shown at right. 2 08 3309 ST --
MAX 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- A value of AGC gain is maximized.
AGC 1) Make setting shown at right. 2 08 330A ST --
MIN 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- A value of AGC gain is minimized.
COLOR 1) Make setting shown at right. 2 08 330B ST --
BAR 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- Outputs color bar from DIGIC DV.
White 1) Make setting shown at right. 2 08 330C ST --
100% 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- Outputs white 100% from DIGIC DV.
White 1) Make setting shown at right. 2 08 330D ST --
50% 2) Execute STORE. (Press PAUSE.)
㸡㸡 㸡
RD -- Outputs white 50% from DIGIC DV.
MONITOR
