11
MECHANICAL PARTS
SYMBOL PART NO. CLASS Q’TY DESCRIPTION REMARKS
MVX250i E, MVX200i E, MVX200 E
PARTS LIST
1 XA1-7170-407 000 F 2 SCREW
2 DA3-1508-000 000 B 1 COVER, LCD TOP MVX250i E NEW
DA3-1552-000 000 B 1 COVER, LCD TOP MVX200i E NEW
DA3-1534-000 000 B 1 COVER, LCD TOP MVX200 E NEW
3 DG3-0400-000 000 C 1 PCB ASS’Y, LCD NEW
4 DA3-1503-000 000 C 1 HOLDER, LCD NEW
5 DA3-1607-000 000 C 4 SHEET, LCD2 NEW
6 DG3-0404-000 000 C 1 BACK LIGHT ASS’Y, LCD NEW
*1 7 DY1-8670-000 000 B 1 LCD ASS’Y(SELECTION) NEW
*2 WG2-5272-000 000 B 1 LCD ASS’Y NEW
8 DA3-1502-000 000 B 1 COVER, LCD BOTTOM MVX250i E NEW
DA3-1510-000 000 B 1 COVER, LCD BOTTOM MVX200i E, MVX200 E NEW
9 DA3-1569-000 000 C 1 SPRING, LCD LOCK NEW
10 DA3-1506-000 000 B 1 KNOB, LCD OPEN NEW
11 DA2-0909-000 000 C 1 SHAFT, LCD LOCK
12 DA3-1504-000 000 B 1 COVER, LCD HINGE TOP MVX250i E NEW
DA3-1544-000 000 B 1 COVER, LCD HINGE TOP MVX200i E, MVX200 E NEW
13 DA2-1737-000 000 1 MAGNET, HINJI
14 DG3-0406-000 000 C 1 HINGE, LCD NEW
15 DH2-5205-000 000 C 1 FPC, LCD-KEY NEW
16 DA3-1505-000 000 B 1 COVER, LCD HINGE BOTTOM NEW
17 XA4-9170-907 000 F 1 SCREW NEW
18 DG3-0419-000 000 C 1 FPC, LCD DETECT NEW
*1 : Free from the pixel dot.
*2 : Same quality as the production line.
