25
MECHANICAL PARTS
SYMBOL PART NO. CLASS Q’TY DESCRIPTION REMARKS
DMC III
PARTS LIST
<Caution> 1 DG1-4506-000 000 B 1 COMPARTMENT ASS’Y, CASSETTE
2 XA1-7140-147 000 C 1 SCREW
3 DA2-2138-000 000 C 4 SCREW
4 DY1-8500-000 000 E 1 DRUM ASS’Y NEW
5 DA2-2139-000 000 C 1 WASHER
6 DF1-1703-000 000 C 1 IDLER ASS’Y
7 DA2-2116-000 000 C 1 SPRING, COIL (DRUM)
8 DA2-2115-000 000 C 1 SCREW
9 DY1-8501-000 000 B 1 CHASSIS ASS’Y, SLIDE
10 DA3-2345-000 000 C 1 COVER, HOUSING NEW
<Caution> : When using this part on the product, replace the Housing Cover with the
DA3-2345-000 (Symbol No.10).
