MVX250i E, MVX200i E, MVX200 E
GENERAL DESCRIPTION OF PRODUCT
29
6-8-5 Number of recorded images / recording time
When a MultiMediaCard is used, the maximum recording time per shot is about 10 sec
(for 320 × 240) or about 30 sec (for 160 × 120).
* The included SDC-8M contains prerecorded title images, therefore the actual number of recorded images will be
less than above.
* The given number of recorded images is only for reference. The number will vary greatly depending on the focal
length, subject and other conditions when taking pictures.
* Windows XP : To connect the ELURA70 / 65 / 60A to a computer, the maximum continuous recording time of
movies on a memory card should be no longer than Approx. 12 minutes in 320 × 240 and 35 minutes in 160 × 120.
SDC-8M SDC-128M
a. Still image recording 1280 × 960dots (SXGA) 640 × 480dots (VGA) 1280 × 960dots (SXGA) 640 × 480dots (VGA)
Super Fine Approx. 6 images Approx. 34 images Approx. 144 images Approx. 709 images
(approx. 850 KB per image) (approx. 175 KB per image) (approx. 850 KB per image) (approx. 175 KB per image)
Fine Approx. 10 images Approx. 50 images Approx. 222 images Approx. 975 images
(approx. 550 KB per image) (approx. 120 KB per image) (approx. 550 KB per image) (approx. 120 KB per image)
Normal Approx. 18 images Approx. 84 images Approx. 409 images Approx. 1560 images
(approx. 300 KB per image) (approx. 65 KB per image) (approx. 300 KB per image) (approx. 65 KB per image)
b. Motion video recording 320 × 240dots 160 × 120 dots 320 × 240 dots 160 × 120 dots
Maximum recording time Approx. 20 sec Approx. 50 sec Approx. 8 minutes Approx. 17 minutes
Data size per second Approx. 250 KB / sec Approx. 120 KB / sec Approx. 250 KB / sec Approx. 120 KB / sec
SDC-512M
a. Still image recording 1280 × 960dots (SXGA) 640 × 480dots (VGA)
Super Fine Approx. 577 images Approx. 2837 images
(approx. 850 KB per image) (approx. 175 KB per image)
Fine Approx. 891 images Approx. 3902 images
(approx. 550KB per image) (approx. 120KB per image)
Normal Approx. 1641 images Approx. 6243 images
(approx. 300 KB per image) (approx. 65 KB per image)
b. Motion video recording 320 × 240dots 160 × 120 dots
Maximum recording time Approx. 33 minutes Approx. 69 minutes
Data size per second Approx. 250 KB / sec Approx. 120 KB / sec
