CAPINTEC, INC. CAPRAC
®
-t
April 2021 SYSTEM SETUP 4-5
connector at the rear of the CAPRAC
®
-t Readout marked “PRINTER”. Attach the
other end to the printer.
Note: Do not attach the printer cable to the 9 pin “D” connector labeled “RS232”.
If the optional printer is a USB version, attach the printer cable to the USB connector
on the rear of the CAPRAC
®
-t Readout marked “PRINTER”. Attach the other end to
the printer.
Note: Do not attach the printer cable to the “PC” connector.
5. For each printer type, verify that the correct paper is installed. (Note: The Slip-Ticket
printer paper is manually inserted at the time of printing.)
ENVIRONMENT REQUIREMENTS
Indoor use only. Pollution Degree 2, Altitude, and Installation Cat. II.
The instrument should be located where the level of the background radiation is as low and
as constant as possible.
The instrument should be located where the temperature is stable within a range of +50°F to
+85°F (+10°C to +30°C) and the maximum relative humidity is 90% non-condensing to
warrant maximum reliability and accuracy.
The instrument should be located where the barometric pressure is within a range of 27 – 31
inches of mercury (91 – 105 kilopascals).
CAUTION: If these environmental requirements are not followed, the instrument may
display erroneous readings.
POWER REQUIREMENTS
CAUTION: If the input voltage to the following items is not within the stated
limits, the unit may not function correctly or may be damaged.
Readout
100-240Vac, 50/60Hz, 230mA
Printers (optional)
Okidata Microline 320 (optional)
120Vac, 60Hz, 0.9A or
230/240Vac, 50/60Hz, 0.5A
Epson LX-300+II printer (optional)
99-132Vac, 50/60Hz, 0.6A (maximum 1.4A depending on the character type)
198-264Vac, 50/60Hz, 0.3A (maximum 1.4A depending on the character type)
