CAPINTEC, INC. CAPRAC
®
-t
4-2 SYSTEM SETUP April 2021
UNPACKING AND INSTALLATION
The instrument is packed and shipped as a complete unit. All the accessories are contained
in the carton. (If an optional printer is included, it will be in separate carton.)
The instrument is shipped in a plastic bag in order to provide a dry and clean environment
during shipment.
CAUTION: Be sure the instrument has reached room temperature prior to opening
the box. (Leave the box in the room 24 hours before opening it.)
1. Remove all outer packing material and tapes. The shipping and packing material
should be saved for future use.
2. The following equipment should be found upon unpacking:
• Readout Unit with Stand Base
• Power Cord
• Well Counter
• Printer (optional)
o Okidata Microline 320, or
o Epson LX-300+II, or
o Epson Slip printer, or
o Epson Roll printer, or
o HP DeskJet 6000/8000 Series Inkjet (or equivalent) Printer.
The Printer should have the following accessories:
• Power Supply
• Printer Ribbon
• Communications Cable
• Roll Paper (If Roll printer ordered)
Note: If Test Sources are ordered, they will be shipped separately.
3. Be sure to remove all tape and protective material from the instrument prior to
connecting to the power line.
ASSEMBLY
Readout/Stand Base
Attach the Readout to the Stand Base using the following instructions. Reference Figure 4-1
Readout/Stand Base Assembly for assembly details.
1. On the sides of Readout (A), remove both of the knobs and all (4) of the washers.
2. Place Stand Base (B) on a flat, sturdy surface.
