CAPINTEC, INC. CAPRAC
®
-t
April 2021 CLEANING AND MAINTENANCE 13-5
SERVICING
The system is covered by a two year limited warranty, under normal conditions of use.
Other than the Readout Unit fuses (reference FUSE SERVICING on page 13-5) and internal
Lithium Coin Battery (reference BATTERY REPLACEMENT on page 13-6), there are no user
serviceable parts contained in the system.
Every five years, the system should be returned to Capintec’s only Authorized Service
Center for a complete verification.
CAPINTEC, Inc.
7 Vreeland Road
Florham Park, NJ 07932
Phone (800) ASK-4CRC
Fax (201) 825-1336
FUSE SERVICING
Readout Fuses
CAUTION: FOR CONTINUED PROTECTION, REPLACE ONLY WITH SAME
TYPE AND RATING OF FUSE(S). A FIRE HAZARD MAY EXIST IF
THE WRONG RATING OF FUSE IS INSTALLED.
Two fuses are located in the power entry module next to the power cord connector on the
back panel of the Readout Unit. These fuses are rated at 2.0A 250Vac delayed type as
specified on the label located directly below the power entry module.
To change these fuses:
1. Turn off the CAPRAC
®
-t power switch and unplug the line cord from the power entry
module.
2. Insert the tip of a small flat bladed screwdriver into the notch of the power entry
module just to the left of the switch. Twist the screwdriver to open the fuse cover
door. (Refer to Figure 13-2 Readout Fuse Replacement).
3. To remove the first of the two fuse carriers, insert the tip of the screwdriver behind the
arrow and pull it out. Repeat this process for the second fuse.
4. Remove the blown fuse(s) from the carrier and replace it (them) with T 2.0AL 250 Volt
fuse(s).
5. Re-insert the fuse carriers with the arrows pointing up.
