Case SDX30 - Page 43

SECTION 2 - MECHANICAL SERVICE
page 2-20
2
nd
Serial Range with ADX Hitch - Starting with Serial Number CBJ0007001
REF DESCRIPTION REF DESCRIPTION
1 PIN, LINCH .438 X 1.375 17 HITCH ASSY
2 BOLT "U" US .375 X 4.0 W X 5.0 D 18 BAR BOLTING
3 BUSHING TNSN 1.75 OD 1.5 ID 19 LUG, WELDABLE HITCH PNT
4 NUT LOCK JAM 1.5-6 THIN YZD 20 BRACE WING PNT
5 NUT .75 UNC GR B YZD 21 PIN ASSY. DRAW 1.00 X 3.50 U.L.
6 NUT, LOCK .75 UNC GR C YZD 22 TUBE, SUPPORT TRUSS/W /HITCH RH
7 NUT, LOCK .375 UNC YZD NYL INS 23 TUBE, SUPPORT TRUSS/W HITCH LH
8 SUPPORT TRUSS/W MAIN FRAME LH 24 BOLT .375 X 2 UNC GR5 YZD
9 SUPPORT TRUSS/W MAIN FRAME RH 25 BOLT .75 X 2.5 UNC GR5 YZD
10 TUBE .375 X 4 X 6 W/ HOLES PTD 26 BOLT .75 X 6 UNC GR8 YZD
11 TUBE, SUPPORT /W CROSS 27 BOLT .75 X 6.5 UNC GR8 YZD
12 WASHER 1.515 ID 2.5 14GA YZD 28 BOLT .75 X 7.5 UNC GR8 YZD
13 TUBE /W COUPLER 29 BOLT .750 X 8.0 GR8 ZND
14 PIVOT LINK/W 30 BOLT .75 X 8.5 UNC GR8 YZD
15 BRACKET MOUNTING 31 PIN, PIVOT 1.5OD X 5.630UL YZD
16 BAR BOLTING 40 PIN, HITCH 1 X 3.5 UL
SDX30 Main Frame Assembly Showing ADX Hitch - 2
nd
Serial Range
