VLAN Tagging for Ethernet Service: Configuration Chapter 14
FA4800 User Manual Release 1.9.40 14-7
Figure 14-3: VLAN tag settings
The choices for Ingress Mode are -
Figure 14-4: VLAN: Ingress modes
The two choices correspond respectively to the two rows of Table 14-1. Choosing Tag
causes the VLAN ID and VLAN Priority fields to become available:
Note
If you are using a new style IDU-E, the SFP row will not appear.
