The Outdoor Unit (ODU) Chapter 1
FA4800 User Manual Release 1.9.40 1-7
Figure 1-8: ODU Form Factors
• Integrated Antenna ODU
This ODU has an integrated 370mm (1.2ft) flat panel antenna. The ODU contains both
the radio and the antenna as a single unit housed in a weatherproof case.
• Connectorized ODU
This ODU has one N-type connector for connecting an external antenna.
There are five series of FA4800 ODU’s:
• FA4800 Access
• FA4800 Access Pro
• FA4800 VS
• FA4800
• FA4800 High End
The following table shows the differences between the four systems:
Front Rear
ConnectorizedIntegrated
Table 1-1: ODU Series Typical Characteristics
FA4800
Access
FA4800
Access Pro
FA4800
VS
FA4800
FA4800
High End
Max Ethernet
Throughput
2Mbps 6Mbps 2/5 Mbps 18Mbps 18Mbps
Max. Range 20Km 80Km 20Km 80Km 80Km
