FibeAir2000 Manager Traps Appendix D
FA4800 User Manual Release 1.9.40 D-27
FibeAir2000 Manager Traps
The FibeAir2000 Manager application issues traps to indicate various events. These traps are
shown in the FibeAir2000 Managerr Events Log.
A list of Trap Messages as displayed by the FibeAir2000 Manager is shown in Table 9-5.
compatibleIdus 228 normal Indicates that the ODU has identified compatible Idus on both sides of the
link.
desiredRatioCanNotBeAppliedClear 229 normal Indicates Current UL/DL Ratio Is Equal To Desired Ratio.
cbwMatch 230 normal Indicates that a Channel Bandwidth match was detected. Contains a
single parameter which is its description: 1 - Channel Bandwidth value
in MHz.
switchCbwAndChannel 231 normal Indicates that the system is switching Channel Bandwidth and channel
frequency. Contains two parameters: 1 - Switching to Channel
Bandwith %n0 MHz and to channel %n1 GHz.
ringRplStateIdle 232 normal RPL state changed to Idle.
ringEthServiceStatus 233 normal Indicates Ethernet service's state - blocked \ unblocked. Contains a
single parameter: 1 - Description: Ethernet's state (blocked \ unblocked)
ringFirstRpmReceived 234 normal Ring application: in non-RPL link indicates first from a specific RPL was
received. Contains a single parameter: 1 - Description: RPM's VLAN ID
ringEthernetSrviceUnblockedTO 235 normal Ring application: in non-RPL link Ethernet service is unblocked due to
RPM timeout.
gpsSynchronized 236 normal Indicates that the GPS is synchronized with satellites.
Table D-3: MIB Traps (Sheet 5 of 5)
Name ID Severity Description
