FA4800 User Manual Release 1.9.40 A-1
Appendix A
Technical Specifications
Scope of these Specifications
This appendix contains technical specifications for the major link components appearing in
this User Manual. They are correct at the date of publication, but are intended for general
background only. The latest authoritative and most up to date technical specifications are
available as Data Sheets obtainable from Ceragon Customer Service.
In any event, Ceragon reserves the right to change these specifications without notice.
ODU
FA4800
Access
Visual
Surveill-
ance
FA4800
Access
Pro
FA4800 and FA4800 HE
Capacity (net throughput, full duplex) 2Mbps 2/5Mbps 6Mbps 18Mbps
Range (Maximum) 20 Km (13 miles) 80 Km (50 miles)
Channel Bandwidth
5MHz for Access, all other models 5MHz, 10MHz and 20MHz (5MHz
Resolution)
Radio Modulation OFDM (BPSK/QPSK/16QAM/64QAM)
Adaptive Modulation & Coding Supported
Automatic Channel Selection Supported
Duplex Technology TDD
Error Correction FEC k = 1/2, 2/3, 3/4
Rate [Mbps] 6 9 12 18 24 26 48 54
Modulation BPSK QPSK 16QAM 64QAM
FEC [k=] 1/2 3/4 1/2 3/4 1/2 3/4 2/3 3/4
Max Tx Power [dBm] 23 20 16
Sensitivity (dBm) @BER <10e-11
(20MHz)
-87 -84 -80 -79 -73 -66 -62
Encryption AES 128
