FA4800 User Manual Release 1.9.40 20-1
Chapter 20
Changing the Factory
Default Band
Why this is Needed
All ODUs supplied by Ceragon come with pre-configured with a factory default product-
dependent band according to the ODU part number.
For ODUs supporting Multi-band, it may be changed using the procedure in this chapter. The
procedure is generic, applying to all ODUs with the Multi-band feature.
Required Equipment
The minimal equipment required to change an ODU default band is:
• Laptop computer (managing computer) satisfying the requirements of Table 4-1.
• An installed copy of the FibeAir2000 Manager
• A PoE device
• A crossed Ethernet LAN cable
• An IDU-ODU cable
The procedure

To change the factory default band:
1. Using the IDU-ODU cable, connect the PoE device to the ODU, ensuring that the
cable is plugged into the PoE port marked P-LAN-OUT.
Caution
• If for some reason the default band needs to be changed, it should
be done before link installation.
• Use of an incorrect band may be in violation of local regulations.
Note
The following procedure is generic to all relevant Ceragon radio products.
What you see on your running FibeAir2000 Manager may differ in some
details from the screen captures used to illustrate this chapter.
