Ceragon FA4800 - DC Power Terminals; DC Poe; Idu-C & E; Table B-8 Terminal Block

DC Power Terminals Appendix B
FA4800 User Manual Release 1.9.40 B-5
DC Power Terminals
IDU-C & E
DC PoE
Table B-8: Terminal Block 3-pin -48VDC
Function Pin
+ Right
Chassis Center
– Left
Table B-9: Terminal Block 2-pin -48VDC
Function Pin
+ Right
– Left
