FA4800 User Manual Release 1.9.40 25-1
Chapter 25
BRS Installation
Procedure
BRS Link Activation
In accordance with 2.5 GHz standard, FA4800-BRS links must be activated before use. This is
done at both ODUs independently before installation on site. Both ODUs must be configured
identically.
To Activate a BRS Link:
1. Install FibeAir2000 Manager software as usual.
2. When the Manager Main Screen is displayed it appears with the Link Status label red
and showing Inactive. The Link Configuration and Link installation buttons are dis-
abled.
Figure 25-1: Inactive link state
3. Click Configuration |Configure Location
The Air Interface dialog box opens:
