MIB Parameters Appendix D
FA4800 User Manual Release 1.9.40 D-10
fibeAir4800OduAirLinkDistance 1.3.6.1.4.1.4458.1000.1.5.29 Integer RO Link distance in meters. A value of -1 indicates
an illegal value and is also used when a link is not
established.
fibeAir4800OduAirLinkWorkingMode 1.3.6.1.4.1.4458.1000.1.5.30 Integer RO Link working mode as a result of comparing
versions of both sides of the link. Possible
modes are: Unknown - no link Normal - versions
on both sides are identical with full compatibility
with restricted compatibility or versions on both
sides are different with software upgrade or
versions incompatibility.
fibeAir4800OduAirMajorLinkIfVersion 1.3.6.1.4.1.4458.1000.1.5.31 Integer RO Major link interface version
fibeAir4800OduAirMinorLinkIfVersion 1.3.6.1.4.1.4458.1000.1.5.32 Integer RO Minor link interface version
fibeAir4800OduAirHssDesiredOpState 1.3.6.1.4.1.4458.1000.1.5.40.1 Integer RW Required Hub Site Synchronization operating
state.
fibeAir4800OduAirHssCurrentOpState 1.3.6.1.4.1.4458.1000.1.5.40.2 Integer RO Current Hub Site Synchronization operating state.
fibeAir4800OduAirHssSyncStatus 1.3.6.1.4.1.4458.1000.1.5.40.3 Integer RO Hub Site Synchronization sync status.
fibeAir4800OduAirHssExtPulseStatus 1.3.6.1.4.1.4458.1000.1.5.40.4 Integer RO Hub Site Synchronization external pulse detection
status. In GSS mode: if generating then 1PSP
is auto generated by the GSS Unit. if
generatingAndDetecting then 1PSP is generated
by GPS satellites signal.
fibeAir4800OduAirHssExtPulseType 1.3.6.1.4.1.4458.1000.1.5.40.5 Integer RO Hub Site Synchronization external pulse type.
fibeAir4800OduAirHssDesiredExtPulseType 1.3.6.1.4.1.4458.1000.1.5.40.6 Integer RW Hub Site Synchronization required external pulse
type. Valid values for read write: {typeA(2)
typeB(3) typeC(4) typeD(5) typeE(6) typeF(7)}.
Valid value for read only: {notApplicable(1)}.
fibeAir4800OduAirHssRfpTable N/A ODU Radio Frame Patterns (RFP) Table.
fibeAir4800OduAirHssRfpEntry N/A ODU RFP Table entry. INDEX {
fibeAir4800OduAirHssRfpIndex }
fibeAir4800OduAirHssRfpIndex 1.3.6.1.4.1.4458.1000.1.5.40.7.1.1 Integer RO ODU RFP Table index. The index represent the
Radio Frame Pattern: typeA(2) typeB(3)
typeC(4) typeD(5) typeE(6).
fibeAir4800OduAirHssRfpEthChannelBW5MH
z
1.3.6.1.4.1.4458.1000.1.5.40.7.1.2 Integer RO Represents the compatibility of Ethernet service
under Channel BW of 5MHz in the specific
Radio Frame Pattern.
fibeAir4800OduAirHssRfpTdmChannelBW5M
Hz
1.3.6.1.4.1.4458.1000.1.5.40.7.1.3 Integer RO Represents the compatibility of TDM service under
Channel BW of 5MHz in the specific Radio
Frame Pattern.
fibeAir4800OduAirHssRfpEthChannelBW10M
Hz
1.3.6.1.4.1.4458.1000.1.5.40.7.1.4 Integer RO Represents the compatibility of Ethernet service
under Channel BW of 10MHz in the specific
Radio Frame Pattern.
fibeAir4800OduAirHssRfpTdmChannelBW10M
Hz
1.3.6.1.4.1.4458.1000.1.5.40.7.1.5 Integer RO Represents the compatibility of TDM service under
Channel BW of 10MHz in the specific Radio
Frame Pattern.
fibeAir4800OduAirHssRfpEthChannelBW20M
Hz
1.3.6.1.4.1.4458.1000.1.5.40.7.1.6 Integer RO Represents the compatibility of Ethernet service
under Channel BW of 20MHz in the specific
Radio Frame Pattern.
fibeAir4800OduAirHssRfpTdmChannelBW20M
Hz
1.3.6.1.4.1.4458.1000.1.5.40.7.1.7 Integer RO Represents the compatibility of TDM service under
Channel BW of 20MHz in the specific Radio
Frame Pattern.
fibeAir4800OduAirHssRfpEthChannelBW40M
Hz
RO Represents the compatibility of Ethernet service
under Channel BW of 40MHz in the specific
Radio Frame Pattern.
fibeAir4800OduAirHssRfpTdmChannelBW40M
Hz
RO Represents the compatibility of TDM service under
Channel BW of 40MHz in the specific Radio
Frame Pattern.
fibeAir4800OduAirHssRfpStr 1.3.6.1.4.1.4458.1000.1.5.40.8 DisplayString RO Hub Site Synchronization supported patterns
Table D-2: Private MIB Parameters (Sheet 6 of 18)
Name OID Type
Access
Description
