MIB Parameters Appendix D
FA4800 User Manual Release 1.9.40 D-12
fibeAir4800OduAirComboNumberOfSubBands 1.3.6.1.4.1.4458.1000.1.5.53.2 Integer RO Represents the number of Multi-band sub bands.
fibeAir4800OduAirComboSwitchSubBand 1.3.6.1.4.1.4458.1000.1.5.53.3 DisplayString RW Switch sub band operation with a given sub band
ID. The get operation retrieves the current sub
band ID.
fibeAir4800OduAirInternalMaxRate 1.3.6.1.4.1.4458.1000.1.5.54 Integer RO Max Ethernet throughput of the site (in Kpbs).
fibeAir4800OduAirCapacityDirection 1.3.6.1.4.1.4458.1000.1.5.55 Integer RW Capacity direction of the site.
fibeAir4800OduAirSpectrumAnalysisOperState 1.3.6.1.4.1.4458.1000.1.5.56.1 Integer RW Spectrum Analysis operation state. The
configurable values are Spectrum Analysis Stop
Start and Restart. Not Supported value indicates
that the feature is not supported on the device.
Not Supported is not a configurable state.
fibeAir4800OduAirRxPowerAntennaA 1.3.6.1.4.1.4458.1000.1.5.56.2 Integer RO Received Signal Strength in dBm of Antenna A.
fibeAir4800OduAirRxPowerAntennaB 1.3.6.1.4.1.4458.1000.1.5.56.3 Integer RO Received Signal Strength in dBm of Antenna B.
fibeAir4800OduAirNumberOfSpectrumChannel
s
1.3.6.1.4.1.4458.1000.1.5.56.4 Integer RO Represents the number of Spectrum Channels.
fibeAir4800OduAirSpectrumChannelTable N/A ODU Spectrum Analysis Channel Table.
fibeAir4800OduAirSpectrumChannelTableEntr
y
N/A ODU Spectrum Analysis Channel Table entry.
INDEX {
fibeAir4800OduAirSpectrumChannelIndex }
fibeAir4800OduAirSpectrumChannelIndex 1.3.6.1.4.1.4458.1000.1.5.56.5.1.1 Integer RO ODU Spectrum Channel index.
fibeAir4800OduAirSpectrumChannelFrequenc
y
1.3.6.1.4.1.4458.1000.1.5.56.5.1.2 Integer RO ODU Spectrum Channel frequency in MHz.
fibeAir4800OduAirSpectrumChannelScanned 1.3.6.1.4.1.4458.1000.1.5.56.5.1.3 Integer read-only
fibeAir4800OduAirSpectrumChannelScanning
Timestamp
1.3.6.1.4.1.4458.1000.1.5.56.5.1.4 TimeTicks RO Channel last scan timestamp in hundredths of a
second since device up time. If the channel was
not scanned than the return value will be 0.
fibeAir4800OduAirSpectrumChannelLastNFAn
tennaA
1.3.6.1.4.1.4458.1000.1.5.56.5.1.5 Integer RO Normalized Noise Floor value in dBm - of Antenna
A - (including 2 neighbor frequencies).
fibeAir4800OduAirSpectrumChannelLastNFAn
tennaB
1.3.6.1.4.1.4458.1000.1.5.56.5.1.6 Integer RO Normalized Noise Floor value in dBm - of Antenna
B - (including 2 neighbor frequencies).
fibeAir4800OduAirSpectrumChannelAverageN
FAntennaA
1.3.6.1.4.1.4458.1000.1.5.56.5.1.7 Integer RO Average normalized Noise Floor value in dBm - of
Antenna A - over all dwells.
fibeAir4800OduAirSpectrumChannelAverageN
FAntennaB
1.3.6.1.4.1.4458.1000.1.5.56.5.1.8 Integer RO Average normalized Noise Floor value in dBm - of
Antenna B - over all dwells.
fibeAir4800OduAirSpectrumChannelMaxNFAn
tennaA
1.3.6.1.4.1.4458.1000.1.5.56.5.1.9 Integer RO Max normalized Noise Floor value in dBm - of
Antenna A - over all dwells.
fibeAir4800OduAirSpectrumChannelMaxNFAn
tennaB
1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
0
Integer RO Max normalized Noise Floor value in dBm - of
Antenna B - over all dwells.
fibeAir4800OduAirSpectrumChannelCACPerfo
rmed
1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
1
Integer RO read-only
fibeAir4800OduAirSpectrumChannelLastCACT
imestamp
1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
2
TimeTicks RO Last CAC performed timestamp in hundredths of a
second since device up time. If no CAC has
performed on the channel the return value will be
0.
fibeAir4800OduAirSpectrumChannelRadarDet
ected
1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
3
Integer RO read-only
fibeAir4800OduAirSpectrumChannelRadarDet
ectionTimestamp
1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
4
TimeTicks RO Last Radar Detection timestamp in hundredths of
a second since device up time. If no Radar has
detected on the channel the return value will be 0.
fibeAir4800OduAirSpectrumChannelAvailable 1.3.6.1.4.1.4458.1000.1.5.56.5.1.1
5
Integer RO read-only
fibeAir4800OduAirAntConfAndRatesStatus 1.3.6.1.4.1.4458.1000.1.5.57 Integer RO Description: Antenna configuration and Rates
status (1 = Single antenna with single data stream
2 = Dual antenna with single data stream 3 = Dual
antenna with dual data stream).
Table D-2: Private MIB Parameters (Sheet 8 of 18)
Name OID Type
Access
Description
