Cisco Dual LTE-Single GPS Multi-band Antenna Installation Guide (4G-LTE-ANTM-O-3-B)
.
Table 2 lists the specifications for the GPS Antenna.
Table 1 Specifications of RF antenna
Operating Frequencies 698-960 MHz
1710-2700 MHz
Polarization Vertical, linear
Nominal Impedance 50 Ohms
Gain
1
(Typical)
1. Total gain, free space test when mounted on a 1-foot diameter ground plane with unused ports
loaded.
2.5 dBi
Maximum Power 3 Watts
VSWR
2
2. Free space Voltage Standing Wave Ratio (VSWR) over all operating frequency ranges when
mounted on a 1-foot diameter ground plane with unused ports loaded.
< 2.5:1
Elevation Plane (3 dB Beamwidth) 30° (nominal)
Azimuth Plane (3 dB Beamwidth) Omni-directional
Connector type SMA-Male
Cable 4 foot RG174 VW-1 compliant
Height 90 mm
Base Diameter 137 mm
Color White, Black, Red or Blue
Flammability UL-94 V0
Environment Indoor and outdoor
Mounting 5/8 inch lug with serrated face nut, optional
adhesive backing (peel-off), 17 sq. inches area
(minimum) on a flat smooth surface, 5/8 inch
diameter hole through mounting surface
Operating and storage temperature -40 to +85 degree C
Ingress Protection
3
3. When mounted per installation instructions.
IP67
