Antenna Selection Table
Planned EOS Antennas
Table 1 Planned EOS Antennas
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
Cisco 4G Indoor Ceiling-Mount Omnidirectional
Antenna (4G-ANTM-OM-CM).
Designed for indoor use with Cisco 3G cellular
Enhanced High-Speed WAN Interface Cards
(EHWICs) and is compatible with Cisco 3G cellular
products using a threaded Neill-Concelman (TNC)
Male connector.
TNC male 1 and 1.5 dBi
700–960 MHz
2 dBi 1448-1511
MHz
1.7 and 3.2 dBi
1700–2200 MHz
3 and 4 dBi
2500–2700 MHz
IR807, IR809, and IR829
IR1101 with P-LTE cellular
module
CGM-3G and CGM-4G
modules in CGR1120 (with
additional adapters & cable
accessories)
Cisco 4G/3G Omnidirectional Dipole Antenna
(4G-LTE-ANTM-D).
The 4G-LTE-ANTM-D omnidirectional dipole
antenna is designed for indoor use with Cisco 4G
and Cisco 3G wireless Integrated Services Routers
Generation 2 (ISRs G2) and Enhanced High-Speed
WAN Interface Cards (EHWICs).
Articulated TNC
male connector
4G LTE 698-960,
1710-2170,
2500-2700 MHz.
2 dBi
IR800
CGR 1000
Connected Grid Modules
Cisco Indoor Swivel-mount Dipole Antenna
(ANT-4G-DP-IN-TNC).
Indoor Swivel-mount Dipole 3G/4G Antenna
supported on the Connected Grid Router 1120 and
is designed to support Cellular/PCS/AWS/MDS,
WiMAX 2100/2300/2500/2600 and global
GSM900/GSM1800/UMTS/LTE2600 bands.
TNC male 4G LTE 698-960,
1710-2400,
2500-2700 MHz
0.5 dBi 698-960
MHz)
2.2 dBi 1710-2700
MHz
IR800
CGR 1000
Connected Grid Modules
Cisco Aironet 6.5-dBi Diversity Patch Antenna
(AIR-ANT2465P-R).
(AEOS date 04/30/2019)
Diversity patch antenna designed for use with
Cisco Aironet access points and bridges but can
be used with any 2.4 GHz Cisco Aironet radio
device that utilizes an RP-TNC connector.
RP-TNC WiFi 2.4G
6.5 dBi
IR829
