Antenna Selection Table
Cisco 5-in-1 Vehicle Mount and Fixed
Infrastructure Antenna (ANT-5-4G2WL2G1-O).
Transportation omnidirectional 5-element antenna
for 2G, 3G, 4G cellular, GPS, and dual-band WiFi
2.4 GHz and 5 GHz.
Note: The ANT-5-4G2WL2G1-O antenna is listed
under multiple antenna guide sections due to
support of multiple technologies.
Cellular – TNC
male
WLAN - RP-TNC
male
GPS – SMA male
2 ports with dual
band WiFi 2.4G/5G.
1 port GPS, and 2
ports for 700-2700
MHz cellular.
4.8 dBi typical, 5.5
dBi max, 2400-2500
MHz
5.8 dBi typical, 7.0
dBi max, 4900-5875
MHz
IR829
Cisco Aironet Dual-band Dipole Antenna
(AIR-ANT2524DB-R, AIR-ANT2524DG-R, and
AIR-ANT2524DW-R).
High-performance, dual-band dipole antenna
designed for use with Cisco Aironet 2.4 GHz and 5
GHz radio products with dual-band
reverse-polarity TNC (RP-TNC) antenna ports.
RP-TNC plug WiFi 2.4G/5G
2 dBi 2.4 GHz
4 dBi 5. GHz
IW3702
IW3702 use case requires
AIR-ACC370-NM-RF coaxial
adapters
Matching antenna color is the
white AIR-ANT2524DW-R
IR829
Matching antenna color is the
black AIR-ANT2524DB-R
Cisco Aironet 2.4 GHz and 5 GHz Dual-Band
Polarization-Diverse Directional Array Antenna
(AIR-ANT2566D4M-R).
Four port dual-band polarization-diverse
directional array antenna. It operates over the 2.4
GHz and 5 GHz Wi-Fi bands. It ships with an
articulating mount for use on flat surfaces and
masts, and is adjustable in both horizontal and
vertical planes.
RP-TNC (with
coupling ring)
2.4 GHz and 5 GHz
6 dBi
IW3702
IW3702 use case requires
AIR-ACC370-NM-RF coaxial
adapters
IR829
Cisco Aironet Dual-Band Omni-Directional
Antenna (AIR-ANT2568VG-N).
Single port dual-band omnidirectional antenna
designed to directly attach to an outdoor access
point or bulkhead N female connector.
Type N-Male 2.4 GHz and 5 GHz
6 dBi 2400 – 2483
MHz
8 dBi 5150 – 5925
MHz
IW-6300, ESW-6300
Cisco Aironet 2.4-GHz/5-GHz 8-dBi Directional
Antenna (AIR-ANT2588P3M-N).
Three port directional patch array with an
articulating mount for use on flat surfaces and
masts and is adjustable in both the horizontal and
vertical planes. Designed for use in indoor and
outdoor environments.
Type N-Female
Bulkhead
2.4 GHz and 5 GHz
8 dBi in both bands
IW-6300, ESW-6300
IW/ESW-6300 must be
configured in dual-band mode.
The middle port of the antenna
is unused. Requires N-type
cables.
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
