Cisco Systems, Inc. www.cisco.com
Outdoor Panel Antenna for WiMAX 1.8,
2.5, and 3.8 GHz
The Outdoor Panel Antenna for WiMAX is designed to cover frequencies from 1.8 to 3.x GHz and support the Cisco CGR 1240
and the 1120 routers. This document provides the antenna specifications and mounting instructions.
 WiMAX 1.8 GHz is designed to cover frequencies from 1.8 to 1.83GHz (ANT-1.8-PNL-OUT-N)
 WiMAX 2.5 GHz is designed to cover frequencies from 2.3 to 2.7 GHz (ANT-2.X-PNL-OUT-N)
 WiMAX 3.x GHz is designed to cover frequencies from 3.3 to 3.8 GHz (ANT-3.X-PNL-OUT-N)
This chapter covers the following topics:
 WiMAX 1.8 GHz Technical Specifications
 WiMAX 2.5 GHz Technical Specifications
 WiMAX 3.8 GHz Technical Specifications
 Safety Warnings
 Antenna Installation
 Connecting the Antenna to the Router
 Obtaining Documentation and Submitting a Service Request
Figure 35-1 Flat Panel WiMAX Antenna
WiMAX 1.8 GHz Technical Specifications
The WiMAX 1.8 GHz antenna features the following:
 Low profile
 Wall mount, pipe mount
 Indoor and outdoors
300643
