Cisco Aironet Dual-Band Omni-Directional Antenna (AIR-ANT2568VG-N)
Communications, Services, and Additional Information
Technical Specifications
Antenna Type Omni-directional
Operating Frequency Range 2400–2483 MHz; 5150–5925 MHz
VSWR 1.5:1 (2400–2483 MHz)
2:1 (5150–5925 MHz)
Nominal Input Impedance 50 Ohms
Gain 6 dBi (2400–2483 MHz)
8 dBi (5150–5925 MHz)
Polarization Vertical
Azimuth Plane Ripple 2 dB (Max)
Elevation Plane 3 dB Beamwidth 24° (2400–2483 MHz)
11° (5150–5925 MHz)
Azimuth Plane 3 dB Beamwidth Omni-directional
Length 14.8 in (377 mm)
Diameter 1.25 in (31.75 mm)
Weight 7.2 oz. (204.1 g)
Connector N-Male
Operational Temperature -22–158°F (-30–70°C)
Storage Temperature -40–185°F (-40–85°C)
Water/Foreign Body Ingress IP67
Wind Rating (Operational) 100 mph (161 kph)
Wind Rating (Survival) 136 mph (218 kph)
