390

Cisco 5-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-5-4G2WL2G1-O)

5275 MHz WLAN Antenna Radiation Patterns

Figure 12 5275 MHz WLAN Antenna Radiation Patterns

5875 MHz WLAN Antenna Radiation Patterns

Figure 13 5875 MHz WLAN Antenna Radiation Patterns

Line Color Description

Blue (

—)Port 1

Red (—)Port 2

Line Color Description

Blue (

—)Port 1

Red (

—)Port 2
