Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Environmental Specifications
Mechanical Specifications
Line Color Description
Blue (—)Port 1
Red (—)Port 2
Table 1 Environmental Specifications for the Cisco ANT-4G-PNL-OUT-N Antenna
Specification Description
Operating temperature range -40 to 158°F (-40 to 70°C)
Storage temperature range -40 to 185°F (-40 to +85°C)
Table 2 Mechanical Specifications for the Cisco ANT-4G-PNL-OUT-N Antenna
Specification Description
Mount style Wall or mast mount
Location Indoor or outdoor
Connector Dual type N female direct connect
Dimensions (width x length x height) 11.61 x 11.61 x 3.23 in. (29.5 x 29.5 x 82 cm)
Weight 3.22 lbs (1.46 kg)
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349233
