Cisco 5-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-5-4G2WL2G1-O)
Table 3 GPS Antenna Radio Frequency Specifications
Environmental and Operational Specifications
Mechanical Specifications
Specification Description
Antenna type Patch
Frequency 1575.42 ± 1 MHz (GPS L1)
Nominal impedance 50 ohms
VSWR 2.0:1 maximum
Amplifier Gain 27 ± 3 dB
DC currant 20 mA maximum
DC voltage 2.7 to 12 V
Isolation, Cellular to GPS 10 dB minimum—1574.42 to 1576.42 MHz
Cellular coexistence tested over multiple bands,
GPS includes coexistence filters.
Polarization RHCP
Radiation pattern Hemispherical
Table 4 Environmental and Operational Specifications for the Cisco ANT-5-4G2WL2G1-O Antenna
Specification Description
Operating temperature range -40 to 158°F (-40 to 70°C)
Storage temperature range -40 to 185°F (-40 to 85°C)
Altitude 15,000 feet. (4.5 km)
Humidity 5 to 95%
Vibration, Shock, Thermal, Corrosion, Seismic Outdoor IP67.
Tested to a variety of appropriate industrial, vehicular,
transportation, and mil-spec standards.
Table 5 Mechanical Specifications for the Cisco ANT-5-4G2WL2G1-O Antenna
Specification Description
Mount style Roof mount, bulkhead
Connector Cellular – TNC male
WLAN - RP-TNC male
GPS – SMA male
Cable type Cellular – RG-58
WLAN – RG-58
GPS – RG-174
