Cisco 5-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-5-4G2WL2G1-O)
Table 2 WLAN Antenna Radio Frequency Specifications
Specification Description
Antenna type Dual element, omnidirectional, 2x2 MIMO
Frequency  2400 to 2500 MHz
 4900 to 5875 MHz
Nominal impedance 50 ohms
VSWR 2.0:1 maximum
Gain  4.8 dBi typical, 5.5 dBi maximum at 2400 to
2500 MHz
 5.8 dBi typical, 7.0 dBi maximum at 4900 to
5875 MHz
Isolation, WLAN to WLAN  20 dB minimum-2400 to 2500 MHz
 20 dB minimum-4900 to 5875 MHz
Isolation, cellular to WLAN  15 dB minimum-1710 to 2700 MHz
 18 dB minimum-2400 to 2500 MHz
 20 dB minimum-1448 to 1511 MHz
 25 dB minimum-4900 to 5875 MHz
 25 dB minimum-698 to 960 MHz
Polarization Linear, Vertical
Radiation pattern Omnidirectional
