Cisco WPAN Yagi Antenna (ANT-WPAN-Y-OUT-N)
Figure 11 960 MHz Antenna Radiation Pattern — Vertical Plane
Environmental and Mechanical Specifications
The following are the Environmental and Mechanical Specifications for the Cisco ANT-WPAN-Y-OUT-N Antenna:
Installing the Antenna
This section contains the following:
Contents of the Antenna Kit
Specification Description
Operating temperature range -40 to 158°F (-40 to 70°C)
Mount style Mast mount
Location Outdoor
Connector 18” RG8 pigtail with N female connector
Dimensions 19.7 x 11.61 x 3.23 in. (50 x 29.5 x 82 cm)
Weight 2.4 lbs (1.1 kg)
Wind rating 201 km/hr (125 mph)
IP rating IP67
Material substance compliance RoHS compliant
