ANT-MP2-I-OUT-M and ANT-MP2-I-O-SS-M Antenna and Cable Kits
Mechanical Specifications
The following is a summary of the monopole antenna specifications:
Radiation Patterns
All radiation patterns, gain, and VSWR were measured with the antenna mounted at the center of a 12-by-12-inch ground
plane.
Specification Cisco Connected Grid Monopole
Antennas
Operating frequency range 698 to 960 MHz
1710 to 2170 MHz
2300 to 2700 MHz
VSWR 2:1 max
Peak gain 698 to 960 MHz 2.8 dBi
Peak gain 1710 to 2170 MHz 4.3 dBi
Peak gain 2300 to 2700 MHz 5.0 dBi
Average gain @15 degrees elevation 698 to 960 MHz 0.9 dBi +/- 1.0 dB
Average gain @15 degrees elevation 1710 to 2170 MHz 3.0 dBi +/- 1.0 dB
Average gain @15 degrees elevation 2300 to 2700 MHz 4.0 dBi +/- 1.0 dB
Efficiency 698 to 960/1710 to 2170/2300 to 2700 MHz: minimum 75%
Polarization Vertical
HPBW Horizontal plane @15 degrees Omni, 360 degree
HPBW Vertical plane 698 to 960 MHz 66 degrees average
HPBW Vertical plane 1710 to 2170 MHz 47 degrees average
HPBW Vertical plane 2300 to 2700 MHz 42 degrees average
Power handling, CW 10 W
Connector type MCX jack
Specification Description
Plastic radome PC/polyester blend, .110 thick min.
Flammability UL94 V-0
Color Cisco gray
Ingress protection IP67
Weight 90 g
Wind-loading 165 MPH
Overall length 3.04 inches
Installation torque 6 to 9 ft/lbs
Installation tool Recommended strap wrench, similar to McMaster Car P/N: 5448A31
Operating temperature -40 to 185 degrees F (-40 to 85 degrees C)
