308
Cisco Multiband Panel Outdoor 3G Antenna (ANT-3G-PNL-OUT-N)
The Multiband Panel Outdoor 3G antenna has Azimuth radiation patterns:
Figure 2 Outdoor 3G Antenna Radiation Patterns
Contents of the Antenna Kit
The contents of the multi-purpose integrated antenna are listed in the following table:
Safety Warnings
WARNING: Avoid using or servicing any equipment that has outdoor connections during an electrical storm.
There may be a risk of electric shock from lightning. Statement 1088
Quantity Description
1 Antenna-mount bracket
1 Elevation adjustable bracket
1 Azimuth adjustable bracket
4 1/4”-20x3/4 carriage bolt
6 1/4”-20 hex nut
6 1/4”-20 spring lock washer
6 1/4”-20 flat washer
2Pipe clamps
ANT-4G-SR-OUT-TNC Multiband low-profile saucer outdoor 4G Antenna
