Cisco Dual Port, Dual Band Vehicle Mount and Fixed Infrastructure WLAN Antenna (ANT-2-WLAN-D-O)
5.55 GHz Antenna Radiation Pattern-Horizontal Plane
Figure 8 5.55 GHz Antenna Radiation Pattern-Horizontal Plane
5.55 GHz Antenna Radiation Patterns-Vertical Plane
Figure 9 5.55 GHz Antenna Radiation Patterns-Vertical Plane
Line Color Description
Blue (
—)Port 1
Red (
—)Port 2
