Cisco Dual Port, Dual Band Vehicle Mount and Fixed Infrastructure WLAN Antenna (ANT-2-WLAN-D-O)
2.46 GHz Antenna Radiation Pattern-Horizontal Plane
Figure 4 2.46 GHz Antenna Radiation Pattern-Horizontal Plane
2.46 GHz Antenna Radiation Patterns-Vertical Plane
Figure 5 2.46 GHz Antenna Radiation Patterns-Vertical Plane
Line Color Description
Blue (
—)Port 1
Red (
—)Port 2
