358

Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)

1950 MHz Antenna Radiation Pattern

 1950 MHz Antenna Radiation Pattern—Horizontal Plane

 1950 MHz Antenna Radiation Pattern—Vertical Plane

Line Color Description

Blue (

—)Port 1

Red (—)Port 2

120

150

180

210

240

270

300

330

349227
