Cisco Indoor/Outdoor Active GPS Antenna (GPS-ACT-ANTM-SMA)
Specifications
Figure 1 Specifications for the Cisco GPS-ACT-ANTM-SMA Antenna
Specification Description
Maximum RF input power 1 W
Power Supply 3-5VDC,
20mA typical @3V
30mA typical @5V
Amplifier Gain 27dB typical @25C
Amplifier Filter Topology Antenna-LNA1-BPF1-LNA2-cable-SMA(m)
connector.
Due to a topology without front end filter
immediately following the antenna, antenna has
the benefit of lower noise figure, but may not be
suitable for collocation with a high power wireless
transceiver.
Connector SMA male
VSWR
1
1. VSWR = voltage standing wave ratio.
2:1 or less
Noise Figure 1.5dB typical @25C
Amplifier Filter Topology Antenna-LNA1-BPF1-LNA2-cable-SMA(m)
connector.
Due to a topology without front end filter
immediately following the antenna, the antenna
has the benefit of a lower noise figure, but may not
be suitable for collocation with a high power
wireless transceiver.
Characteristic impedance 50 Ohm
Antenna base and radome color Black
Antenna dimensions 1.7 (L) x 1.4 (W) x 0.55 (H) in.
(44 x 36 x 14mm)
Operating temperature –40° to 185°F (–40° to 85°C)
Operating frequency ranges 1574.42-1576.42 MHz
Polarization RHCP
2
2. RHCP = right hand circularly polarized.
Maximum peak gain (at Boresight) 4 dBic
Shocks 50G
Drop test 10x3 axis / 1 meter drop 6 axis
Cable Length 17 foot (5.18 meters)
Mount Bracket Metal
Anchor 1 inch. The anchor drill size is 3/16.
Screws 3 stainless-steel screws that are self-drilling pan
head #2 Phillips.
