Cisco WPAN Dipole Antenna (ANT-WPAN-OD-OUT-N)
Radiation Patterns
The following diagrams illustrate the radiation patterns for the Cisco ANT-WPAN-OD-OUT-N Antenna:
Specification Description
Antenna Type Dipole
Operating frequency range 863 to 928 MHz
Nominal impedance 50 ohms
VSWR 2.0:1 maximum
Gain 1.5 dBi maximum
3 dB beamwidth (vertical plane) 84 degrees
3 dB beamwidth (horizontal plane) 360 degrees
Polarization Linear, vertical
Radiation Pattern Omnidirectional
Maximum input power 20 Watts
