391
Cisco 5-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-5-4G2WL2G1-O)
GPS Radiation Patterns
1575 MHz GPS Antenna Radiation Patterns
Figure 14 1575 MHz GPS Antenna Radiation Patterns
Installing the Antenna
The antenna installation includes the following procedures:
Contents of the Antenna Kit
Line Color Description
Blue (
—)Port 1
Red (
—)Port 2
