Cisco 4G LTEA, 4G LTE, and 3G Omnidirectional Dipole Antenna (LTE-ANTM-SMA-D)
Antenna Radiation Patterns
Figure 2 698, 824, 960 MHz Cellular Antenna Radiation Pattern (dBi), Azimuth
-40
-35
-30
-25
-20
-15
-10
-5
0
5
0
30
60
90
120
150
180
210
240
270
300
330
Gain (dBi
)
Phi Angle (°)
XY Plane
366531
Y
X
698MHz 824MHz 960MHz
0.72
1.31
360
-1.37
0.02
235
-0.87
0.52
305
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
698MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
824MHz
Avg (dBi) =
Peak (dBi) =
Avg -3 (deg) =
960MHz
