Cisco Cellular 2-in-1 Vehicle Mount and Fixed Infrastructure Antenna (ANT-2-4G2-O)
Radio Frequency Specifications
Antenna Radiation Patterns
 698 MHz Cellular Antenna Radiation Patterns
 880 MHz Cellular Antenna Radiation Patterns
 960 MHz Cellular Antenna Radiation Patterns
 1470 MHz Cellular Antenna Radiation Patterns
 1710 MHz Cellular Antenna Radiation Patterns
 2170 MHz Cellular Antenna Radiation Patterns
 2700 MHz Cellular Antenna Radiation Patterns
Figure 3 Cellular Antenna Radio Frequency Specification
Specification Description
Antenna type Dual element, omnidirectional, 2x2 MIMO
Frequency  698 to 960 MHz
 1448 to 1511 MHz
 1710 to 2700 MHz
Nominal impedance 50 ohms
VSWR  2.1:1 maximum-698 to 960 MHz
 2.4:1 maximum at 1448 MHz edge, 2.2:1
typical 1448-1511 MHz
 2.0:1 maximum-1710 to 2700 MHz
Gain The gain values (dBi) for each frequency range
are:
 2.6 dBi typical, 3.8 dBi maximum-698 to 960
MHz
 3.8 dBI typical, 4.3 dBI maximum 1448 to
1511 MHz
 4.6 dBi typical, 5.5 dBI5 dBI maximum-1710
to 2700 MHz
Isolation
Cellular to cellular
(Main to Aux)
 15 dB minimum - 698 to 960 MHz
 20 dB minimum - 1448 to 1511 MHz
 20 dB minimum - 1710 to 2700 MHz
Efficiency Antennas were designed and tested to high RF
efficiency in all supported cellular bands. Detailed
technical specifications can be obtained through
your Cisco authorized partner or Cisco account
representative.
Polarization Linear, Vertical
Radiation Pattern Omnidirectional

Cisco AIR-ANT2544V4M-R Specifications

General

Brand	Cisco
Model	AIR-ANT2544V4M-R
Category	Antenna
Language	English
