Antenna Selection Table
Dual Band 2.4 GHz + 5 GHz Antennas
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
Cisco Dual Port, Dual Band Vehicle Mount and
Fixed Infrastructure WLAN Antenna
(ANT-2-WLAN-D-O).
Dual Port, Dual Band Outdoor Vehicle Mount and
Fixed Infrastructure WLAN Antenna,
omnidirectional, vertically polarized, 2x2 MIMO,
integrated 3 foot long LMR-240 cables with
RP-TNC plug connectors.
2 x 3 foot
LMR-240 cables
with
RP-TNC(plug)
connectors
WiFi 2.4G/5G
4.0 dBi typical, 5.1
dBi max 2400-2500
MHz
6.5 dBi typical, 7.0
dBi max 4900-5875
MHz
IR829
Cisco Aironet Four-Port Dual-Band
Polarization-Diverse Antenna
(AIR-ANT2513P4M-N).
Four-port polarization-diverse patch array with an
articulating mount for use on flat surfaces and
masts, and is adjustable in both the horizontal and
vertical planes. Designed for use in indoor and
outdoor environments.
Type N-Female
Bulkhead
WiFi 2.4G / 5G
13 dBi
IW3702, IW-6300, ESW-6300
Requires N-type cables
Cisco Aironet Four-Element, MIMO, Dual-Band
Ceiling Mount Omni-Directional Antenna
(AIR-ANT2524V4C-R).
Four-element, dual-band antenna designed for
ceiling-mounting in an indoor environment.
RP-TNC WiFi
2.4 GHz band: 2 dBi
5 GHz band: 4 dBi
IW3702
IW3702 use case requires
AIR-ACC370-NM-RF coaxial
adapters
Cisco Aironet Dual-Band MIMO Wall-Mounted
Omnidirectional Antenna (AIR-ANT2544V4M-R).
Four port dual-band wall-mounted omnidirectional
antenna designed for indoor or outdoor use.
RP-TNC WiFi
2.4 GHz band: 4 dBi
5 GHz band: 4 dBi
IW3702
IW3702 use case requires
AIR-ACC370-NM-RF coaxial
adapters
Cisco Aironet Dual-Band Omni-Directional
Antenna (AIR-ANT2547V-N,
AIR-ANT2547V-N-HZ, and ANT2547VG-N).
Single port dual-band omni-directional antenna
designed to directly attach to an outdoor access
point or bulkhead N female connector.
Type N-Male WiFi
4 dBi 2400–2483
MHz
7 dBi 5250–5875
MHz
IW3702, IW-6300, ESW-6300
IR829
IR829 use case requires cables
and adapters.
Cisco Aironet 2.4-GHz/5-GHz MIMO 4-Element
Patch Antenna (AIR-ANT2566P4W-R).
4-Element Patch Antenna designed for indoor and
outdoor use.
RP-TNC WiFi 2.4G/5G
6 dBi in both bands
IW3702
IW3702 use case requires
AIR-ACC370-NM-RF coaxial
adapters

Cisco AIR-ANT2544V4M-R Specifications

General

Brand	Cisco
Model	AIR-ANT2544V4M-R
Category	Antenna
Language	English
