Antenna Selection Table
GPS/GNSS Antennas
Part Number / Description RF Connectors Antenna Frequency
Band Support and
Gain
Industrial Products Where
Supported
Cisco 5-in-1 Vehicle Mount and Fixed
Infrastructure Antenna (ANT-5-4G2WL2G1-O).
Transportation omnidirectional 5-element antenna
for 2G, 3G, 4G cellular, GPS, and dual-band WiFi
2.4 GHz and 5 GHz.
The ANT-5-4G2WL2G1-O integrated GPS RF
front end is designed to reject collocated RF
interference.
Note: The ANT-5-4G2WL2G1-O antenna is listed
under multiple antenna guide sections due to
support of multiple technologies.
Cellular – TNC
male
WLAN - RP-TNC
male
GPS – SMA male
1 dBi zenith, plus
27dB amplifier gain
4G LTE 698-960,
1448-1511,
1710-2400,
2500-2700 MHz
Plus 1 port GPS, and
2 ports for dual band
WiFi.
1575.42 +/- 1 MHz,
GPS L1
Good fit for IR829.
Can be used with other
products such as IR809 or
IR807, but has extra WiFi
elements not required for those
products.
Instead consider
ANT-3-4G2G1-O for products
without WiFi.
Cisco Cellular and GPS 3-in-1 Vehicle Mount and
Fixed Infrastructure Antenna (ANT-3-4G2G1-O).
Three port antenna with two elements designed to
cover the 698-960, 1448-1511 and 1710-2700
MHz cellular bands and one GPS element.
The ANT-3-4G2G1-O antenna is listed under
multiple antenna guide sections due to support of
multiple technologies.
The ANT-3-4G2G1-O integrated GPS RF front end
is designed to reject collocated RF interference.
Cellular – TNC
male
GPS – SMA male
1 dBi zenith, plus
27dB amplifier gain
Active GPS antenna,
1575.42 +/- 5 MHz
IR807, IR809, and IR829
IR1101 with P-LTE cellular
module
C819HG-LTE and C819HG-4G
CGM-3G and CGM-4G
modules with CGR1120 router
CGR1120 use case requires
ANT-ADPTR-Q-TNC adapters,
as CGR1120 router has a
QMA(f) GPS connector, and
CGM-3G and CGM-4G
modules have QMA(f) cellular
connectors
