Cisco AIR-ANT2544V4M-R Guide

31
Antenna Selection Table
Cisco Integrated 4G Low-profile Outdoor
Saucer Antenna
(ANT-4G-SR-OUT-TNC).
Integrated 4G Low-profile Outdoor
Saucer Antenna.
15 foot LMR 195
cable with TNC(m)
0.8 dBi 698-960 MHz
0.5 dBi 1448-1511 MHz
0.2 dBi 1710-2700 MHz
IR807, IR809, and IR829
C819HG-LTE and
C819HG-4G
CGM-3G and CGM-4G
modules with CGR1120 and
CGR1240.
For CGM / CGR use case
adapters are required.
Cisco 3G/4G LTE and LTEA
Omnidirectional Dipole Antenna
(LTE-ANTM-D).
LTE-ANTM-D is a high performance
indoor antenna for use in the 698-960,
1448-1511 and 1710-2690 MHz
frequency bands.
LTE-ANTM-D antennas have high
standalone efficiency, and maintain high
efficiency when directly installed on front
plate of a small or medium size Cisco
router. However, depending on chassis
size and a variety of other
electromagnetic considerations, installing
the antenna directly on the chassis is not
always recommended.
1 x TNC(m) 2 dBi, 698-960 MHz
2.8 dBi, 1447-1511 MHz
3.7 dBi, 1710-2690 MHz
IR807, IR809, and IR829
C819HG-LTE and
C819HG-4G
CGM-3G and CGM-4G
modules in CGR1120 (with
additional adapters & cable
accessories)
Cisco 4G LTEA, 4G LTE, and 3G
Omnidirectional Dipole Antenna
(LTE-ANTM-SMA-D).
LTE-ANTM-SMA-D is a high performance
indoor antenna for use in the 698-960,
1448-1511 and 1710-2690 MHz
frequency bands.
LTE-ANTM-SMA-D antennas have high
standalone efficiency, and maintain high
efficiency when directly installed on front
plate of a small or medium size Cisco
router. However, depending on chassis
size and a variety of other
electromagnetic considerations, installing
the antenna directly on the chassis is not
always recommended.
1 x SMA(m) 2 dBi, 698-960 MHz
2.8 dBi, 1447-1511 MHz
3.7 dBi, 1710-2690 MHz
IR1101 with P-LTE cellular
module
Part Number / Description RF Connectors Antenna Frequency Band
Support and Gain
Industrial Products Where
Supported
