Cisco Aironet Four-Port Dual-Band Polarization-Diverse Antenna (AIR-ANT2513P4M-N)
Technical Specifications
Figure 1 ANT2513P4M-N front high view
2.4 GHz Antenna Radiation Patterns
Antenna Type Dual-Band Polarization Diverse Patch Array
Operating Frequency Ranges 2.4-2.5 GHz 5.15-5.925 GHz
Nominal Input Impedance 50 Ohms 50 Ohms
VSWR 1.6:1 1.5:1 (above 5.7 GHz to 5.9 GHz)
2:1 (from 5.15 GHz to 5.7 GHz)
Peak Gain 13 dBi 13 dBi
Polarization (Ports A & C) Vertical Vertical
Polarization (Ports B & D) Horizontal Horizontal
Nominal Elevation Plane 3-dB Beamwidth 33 Degrees 27 Degrees
Nominal Azimuth Plane 3-dB Beamwidth 31 Degrees 31 Degrees
V-Pol Maximum Sidelobe Level -15 dBc -12 dBc
H-Pol Maximum Sidelobe Level -10 dBc -12 dBc
Front-to-Back Ratio > 30 dB > 30 dB
Connector Type N-Female Bulkhead
Length 14.5 in. (36.8 cm)
Width 20 in. (50.7 cm)
Height 0.8 in. (2.11 cm)
Weight 81.1 oz. (2.3 kg)
Water/Foreign Body Ingress IP67
Operational Wind 100 MPH
Operating Temperature Range -40° C to 85° C
