Outdoor Panel Antenna for WiMAX 1.8, 2.5, and 3.8 GHz
Safety Warnings
WARNING: Avoid using or servicing any equipment that has outdoor connections during an electrical storm.
There may be a risk of electric shock from lightning. Statement 1088
WARNING: Do not work on the system, or connect or disconnect cables, during periods of lightning activity. Statement 1001
WARNING: Do not locate the outdoor antenna near overhead power lines or other electric light or power circuits, or where it can
come into contact with such circuits. When installing the antenna, take extreme care not to come into contact with such circuits,
as they may cause serious injury or death. For proper installation and grounding of the antenna, please refer to national and local
codes (for example, U.S.:NFPA 70, National Electrical Code, Article 810, Canada:Canadian Electrical Code, Section 54).
Statement 1052
WARNING: This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of
a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain
that suitable grounding is available. Statement 1024
WARNING: Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement 1030
WARNING: To report a gas leak, do not use a telephone in the vicinity of the leak. Statement 1039
WARNING: This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing
accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety
warnings that accompanied this device. Statement 1071. SAVE THESE INSTRUCTIONS.
WARNING: This product is not intended to be directly connected to the Cable Distribution System. Additional regulatory
compliance and legal requirements may apply for direct connection to the Cable Distribution System. This product may connect
to the Cable Distribution System ONLY through a device that is approved for direct connection. Statement 1078
WARNING: This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing
accidents.
Specification Description
Type Directional panel
Frequency 3.3 to 3.8 GHz
Nominal gain 18 dBi
Polarization Dual linear (vertical and horizontal) or slant +/- 45 degrees
Maximum input power 25 Watts
Antenna size 14.5 x 14.5 x 1.75 in. (36.8 x 36.8 x 4.4 cm)
Weight 3.5 lbs (1.6 kg)
Connector Dual type N female
Mount Style Wall or pipe mount
Environment Outdoor
Temperature range (operating) -40 to 185-degrees F (-40 to 85-degrees C)
Radiation pattern Directional
