Cisco RF Cables and Accessories
Cellular Antenna Extension Bases
The following tables provide information for the Extension Bases supported by Cisco.
Table 9 Extension Bases
Extension Base PID Description RF Loss
4G-AE010-R TNC(m)-STR to TNC(f)-STR
LMR-195, 10 foot RF cable
Type: Plenum
Antenna extension bases
1.1dB @ 0.7 GHz
1.4dB @ 1.0 GHz
1.8dB @ 1.7 GHz
2.1dB @ 2.4 GHz
2.3dB @ 2.7 GHz
4G-AE015-R TNC(m)-STR to TNC(f)-STR
LMR-195, 15 foot RF cable
Type: Plenum
Antenna extension bases
1.7dB @ 0.7 GHz
2.0dB @ 1.0 GHz
2.6dB @ 1.7 GHz
3.2dB @ 2.4 GHz
3.4dB @ 2.7 GHz
LTE-AE-MAG-SMA TNC(f)-STR to SMA(f)-STR
LMR-195, 1ft RF cable
Type: Plenum
Antenna extension bases
0.2dB @ 0.7 GHz
0.2dB @ 1.0 GHz
0.3dB @ 1.7 GHz
0.3dB @ 2.4 GHz
0.3dB @ 2.7 GHz
